LenoRF DC blocks are passive coaxial components that prevent (block) the flow of direct current (DC) frequencies to RF signals.
F DC filter blocks from LenoRF are available in 50 Ohm and 75 Ohm designs at varying frequency ranges.
Our RF DC blocks are RoHS and REACH compliant.
| Part No || DCF-002 |
| Description || Microwave DC filter F female to female |
| Connector Type || Female Female |
| Frequency || DC-6G |
| VSWR || ≤1.25 |
| Insertion Loss || ≤0.2dB |
| Impedance || 50 ohms |
| Voltage Rating || 375V |
| Body Material || Brass |
| Body Finish || Nickle /Ternary Alloy |
| Waterproof || IP65 |
| Working Temperature || -65°C ~ 165°C |
