Low Loss Phase Stable Cable's basic structure and advantages

Low Loss Phase Stable Cable, referred to as Phase Stable Cable is a high-tech product in the field of RF cables. It uses microporous PTFE tape-wrapped insulation, silver-plated copper foil wrapped with a braided outer conductor, and FEP sheath structure form, with low loss, high phase stability, and high power and other electrical properties. Next, let's look at what are its common structural components.

The following is a list of the catalog：

• The basic structure of Low Loss Phase Stable Cable

• Advantages of Low Loss Phase Stable Cable

The basic structure of Low Loss Phase Stable Cable

Low Loss Phase Stable Cable is designed concerning the national standard parameters. In addition to the basic mechanical performance requirements of the conductor, it also takes into account the skin effect of RF signal transmission in the inner conductor.

Low Loss Phase Stable Cable's process data is digitized and the pitch tolerance is not specified in the documentation to achieve an excellent winding process.

Low Loss Phase Stable Cable's outer conductor uses silver-plated copper flat tape and silver-plated copper wire braid double structure, to achieve low loss and phase stability purposes. Therefore, when producing Low Loss Phase Stable Cable, we need to adjust the winding angle to the best condition.

Advantages of Low Loss Phase Stable Cable

1. Low Loss Phase Stable Cable has low voltage VSWR.

2. Low Loss Phase Stable Cable has low attenuation.

3. Low Loss Phase Stable Cable has excellent phase stability.

4. Low Loss Phase Stable Cable has excellent phase consistency.

5. Low Loss Phase Stable Cable has anti-aging.

The conductor of Low Loss Phase Stable Cable generally uses a single silver-plated soft round copper wire. It improves the frequency range, standing wave, attenuation, and phase performance as well as good stability compared to ordinary RF cables. Low Loss Phase Stable Cable has a high cost-performance ratio and it is one of the options for people to choose

low-loss and low-cost solutions according to their requirements.

1. The electrical performance of Low Loss Phase Stable Cable: transmission speed 83%, and also has the advantages of low loss, low VSWR, and high shielding efficiency.

2. The mechanical performance of Low Loss Phase Stable Cable: Because the cable is braided with a flat ribbon, the cable has strong twist resistance and good flexibility.

3. The environmental resistance of Low Loss Phase Stable Cable: Low loss series cables use high-quality raw materials with environmental resistance, making them resistant to wear and tear, high bending life, and other advantages. The use of temperature is in -55 ℃ ~ +85 ℃ / -55 ℃ -125 within.

It is the responsibility of each manufacturer to produce a Low Loss Phase Stable Cable that meets the standards, to ensure the safety of its supply and the healthy development of the Low Loss Phase Stable Cable market. Zhenjiang LenoRF Industry co. LTD- LenoRF conducts many tests on Low Loss Phase Stable Cable for connection before they leave the factory, and the quality qualification rate is guaranteed. If you are interested in it, you can consider our cost-effective products.
