Overview
An RF terminator (also called a load or dummy load) is a passive device used to absorb RF energy and prevent signal reflections in transmission lines or unused ports. It provides proper impedance matching typically 50 ohm or 75 ohm ensure system stability and minimize standing waves (VSWR). By safely dissipating RF energy as heat, terminators maintain signal integrity and protect equipment from damage caused by mismatched or open-ended lines.
Features
Impedance: Commonly 50 ohm (for RF/microwave systems) or 75 ohm (for broadcast and video systems).
Frequency Range: Available up to 110 GHz depending on the design.
VSWR Performance: Low VSWR ensures minimal reflection across the operating frequency band.
Cooling: High-power terminators may use heatsinks or forced air for thermal management.
Applications
Terminating unused RF ports on splitters, couplers, or test equipment
Simulating system loads during design and testing
Absorbing excess RF power in transmitters or amplifiers
Ensuring stable operation of distributed antenna or broadcast systems
robotics and industrial automation requiring RF links
smart meters and remote monitoring devices
Specification
Power | 5W |
Frequency | DC-6GHz |
VSWR | ≦1.20 |
Impedance | 50 ohm |
RF Connector | N-male |
Working Temperature | -55 ~ +125 ℃ |
