SMA Plug Quick Connect To SMA Jack Adapter

Features:
Thread coupling Mechanism
Crimping or soldering contact
50 impedance up to 18GHz
Light weight,compact design
Anti-vibration performance
Quick Connect
  • 900-2074

  • Male

  • Straight

  • Crimping

  • Crimping

Availability:
Quantity:
Series 1SMA Plug Quick Connect
Series 2SMA Jack
Body PlatingGold
Body MaterialBrass
Contact PlatingGold
Contact MaterialBeryllium   Copper
Contact TerminationSolder
Coupling MechanismThreaded
HS Code8536909000
Frequency (Max GHz)7.5
Impedance (Ohms)50
Insulator MaterialPTFE
OrientationStraight
Temperature Range-65   ~165 °C
Mating Cycles500   Min


FAQ

1. Sample delivery time

Regular model need 15 days, some complex connectors need 25 days


2. Sample Fee

The most of RF connector is CNC parts,don't need to make mold.

Through, each part need be tuning the CNC, usually one sample need 200 USD cost.

The fee will return after 5K bulk order


3. The quarantee

Brass RF connector is one year, the stainless steel connector is three year.

Also, depend on the material of contact, Beryllium contact have better lifetime.


4. ROHS&REACH

Our product fully compliance with ROHS&REACH.


5.Does LENORF offer military class product

Yes. We honor to offer military product with super stable quality.


6. MOQ

Regular connector: 500PCS.

Adaptor:100PCS

Military connector:100PCS


Application:

Telecommunication,Military,Broadband,Industry,Medical,5G,Radar
