Solderless 1.85mm connector PCB angled features, considerations, and applications

Solderless 1.85mm connector PCB angled provides low return loss values for frequencies up to 110 GHz. These 30° angled connectors are designed for single or multi-layer printed circuit boards (PCB) where the microwave layer is on top. The angled solderless PCB connectors use screws and pre-positioning pins for easy installation. The mode-free design of this series allows these connectors to provide high RF performance in test and measurement applications.

The following is a list of catalogs:

• l Features of the Solderless 1.85mm connector PCB angled

• l Notes for Solderless 1.85mm connector PCB angled

• l Applications for Solderless 1.85mm connector PCB angled

Features of the Solderless 1.85mm connector PCB angled

1. It has a solderless compression mounting bracket for fast and easy installation (screw included).

2. It has a cost-effective test solution.

3. It has a durable and robust design.

4. It has a customized PCB footprint through analog optimized design.

5. It has a COTS version that can be released at any time.

6. It has adjustable for multiple PCB thicknesses.

7. It has minimal reflection by impedance-matching PCB mounting.

8. It has SMA, 2.92mm, 2.4mm, and 1.85mm series available.

Notes for Solderless 1.85mm connector PCB angled

Poor quality or worn connectors can damage the interface of other expensive instruments and cables. Therefore, daily use of connectors must be used with care.

1. When using the solderless 1.85mm connector PCB angled, the wrong torque wrench should not be used to screw the connector. The reason for using a torque wrench is to ensure that the same force is applied to the connector each time, i.e., the same tightness each time so that repeatable measurements can be obtained and the connector cannot be damaged by excessive force. Therefore, different connectors require different torque wrenches due to their size, material, and properties. There are also times when the torque wrench is chosen correctly, but, still, it causes damage to the connector. Why is that? Simply, you are using the wrong method. Yes, the method is important, for example, the torque wrench grasps the position, angle, and so on.

2. Do not screw the solderless 1.85mm connector PCB angled with bare hands, otherwise, it will damage it.

Applications for Solderless 1.85mm connector PCB angled

1. It is applicated to RF test and measurement boards.

2. It is applicated in rapid prototyping.

3. It is applicated in high-speed digital component testing.

4. It is applicated in military and aerospace.

Solderless 1.85mm connector PCB angled a wide range of applications, many audiences, choose the regular manufacturers of products that can be used for a long time. After all, electrical safety is very important. PCB series connectors range of use: for medical aviation, railroad projects, industrial projects, astronautics projects, monitoring, test instruments ship systems, electric Sightseeing vehicles, UPS, communications power supply, chargers, environmental protection batteries, and other products preferred high-current connectors. The connectors are made of PBT material, which has excellent electronic and motor characteristics and can be widely used for industrial needs.

Our company supports one year warranty for a solderless 1.85mm connector PCB angled. . We have professional customer service, encompassing pre-sales, in-sales, and after-sales services to meet customer demands. If there are any questions about the solderless 1.85mm connector PCB angled, please don't hesitate to contact us. Contact us to learn more! Our website is www.rfcnn.com
