Features
Frequency range up to 110 GHz
50 Ohm impedance with low VSWR
Threaded coupling,vibration-resistant connection
Stainless steel housing, beryllium copper contacts, gold-plated/passivated for durability
Air dielectric design for low insertion loss and high repeatability
Available in jack, plug, flange-mount, and PCB-mount versions
Ideal for mmWave, 5G, and test & measurement environments
Applications
High-frequency test systems
MRI, CT, and ultrasound imaging devices
Patient monitoring systems with wireless connectivity
Railway communications and signaling systems
mmWave modules
5G/6G R&D
lab-grade measurements
GPS & Navigation Systems
Specification
Body Plating | Passivated |
Body Material | Stainless Steel |
Contact Plating | Gold |
Contact Material | Beryllium Copper |
Coupling Mechanism | Threaded |
HS Code | 8536909000 |
Frequency (Max GHz) | 110 |
Impedance (Ohms) | 50 |
Insulator Material | PEI/PTFE |
Size Category | Sub Miniature |
Temperature Range | -65 to 165 °C |
Thread Direction | Standard |
Mating Cycles | 500 Min |
Interface Specification | IEC 61169-31:1999 |
FAQ
Sample Delivery Time
Regular models require 15 days, while some complex connectors require 25 days.
Sample Fee
Most RF connectors are CNC-machined parts and do not require mold-making.
However, each part needs to be fine-tuned on the CNC machine. Typically, a single sample costs $200.
This fee will be refunded after a 5K bulk order.
Guarantee
Brass RF connectors come with a one-year warranty.
Stainless steel connectors come with a three-year warranty.
The lifespan also depends on the contact material—beryllium contacts offer better durability.
ROHS & REACH Compliance
Our products fully comply with ROHS & REACH regulations.
Does LENORF Offer Military-Grade Products?
Yes. We are honored to provide military-grade products with exceptionally stable quality.
MOQ (Minimum Order Quantity)
What is the difference between RF connectors and coaxial connectors?
They are often used interchangeably. However: Coaxial connector refers to the physical design (shielded cylindrical form). RF connector emphasizes its use in radio-frequency applications. Most RF connectors are coaxial.
Regular connectors: 500 PCS
Adapters: 100 PCS
Military connectors: 100 PCS
What are typical applications of RF connectors?
Telecom (5G, LTE, satellite) Aerospace & defense (radar, avionics, secure comms) Test & measurement (network/spectrum analyzers) Broadcast & video distribution Automotive radar and IoT devices Medical imaging & equipment
Materials
Common materials include:
Body: Brass, stainless steel
Insulator: PTFE, PEEK
Contacts: Brass, phosphor bronze, beryllium copper
Other: Aluminum, titanium alloy
