SMP Connectors Plug Solder Straight For RG405 Cable

Overview

The SMP RF Connector is a compact, high-performance connector designed for high-frequency applications up to 40 GHz. With push-on and snap-on mating, it ensures durability and ease of use in RF systems.

Key Features of SMP Connectors

• High-Frequency Performance: Supports frequencies from DC to 40 GHz.

• Compact & Lightweight: Ideal for miniaturized RF systems.

• Push-On & Snap-On Coupling: Allows easy mating and demating, reducing wear.

• Multiple Engagement Options: Standard, Limited Detent, and Full Detent for varying retention forces.

• Good Tolerance Compensation: Allows misalignment in board-to-board connections.

• Durable Materials: Typically made from gold-plated beryllium copper (BeCu) or stainless steel.

Applications of SMP Connectors

• Military & Aerospace Systems (e.g., radar, avionics, SATCOM)

• High-Speed Telecommunications (e.g., 5G, RF backhaul, network infrastructure)

• Test & Measurement Equipment (e.g., spectrum analyzers, oscilloscopes)

• Medical Imaging & Devices (e.g., MRI, ultrasound systems)

• Automotive Radar & ADAS (e.g., self-driving vehicle sensors)

Specification
