Overview
An RF adaptor (Radio Frequency adapter) is a component used to connect two RF connectors or interfaces - either of different types or the same type. It enables the transmission of high-frequency signals with minimal loss or interference, and is typically used in the following applications: electronic warfare, military radios, and secure communication links,missile guidance, drones, and satellite payload systems,radar systems, avionics, and navigation equipment .
Application
Connecting antennas to RF equipment
Linking test equipment (like spectrum analyzers or signal generators) to DUTs (devices under test)
Integrating components in RF communication systems (e.g., Wi-Fi, LTE, GPS, IoT modules)
electronic warfare, military radios, and secure communication links
missile guidance, drones, and satellite payload systems
radar systems, avionics, and navigation equipment
Connector Type:
DIN 7/16
Connector Feature:
Frequency Range:DC – 7.5 GHz
Impedance:50 OHMS
Power Handling:Very High (kW)
Coupling Mechanism:Threaded
Durability (mating cycles):500
Typical Applications:Base stations, high power
Size Category:Very Large
Specification
| Connector Type | DIN 7/16 Connector |
| Type Of Adapter | In Series |
| Body Finish | Tri-Metal |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Phorsphor Bronze |
| Coupling Mechanism | Threaded |
| HS Code | 8536909000 |
| Frequency (Max GHz) | 7.5 |
| Impedance (Ohms) | 50 |
| Orientation | Right angle |
| Temperature Range | -65~165 ° C |
